PS30-50 Fixed Firefighting Water Monitor consists of base, shell, nozzle, gun barrel, horizontal rotary bodies etc, PS30-50 Fixed Fire Fighting Water Monitor can be used for horizontal rotation, pitch
Contact Us Product CenterPS30-50 Fixed Firefighting Water Monitor consists of base, shell, nozzle, gun barrel, horizontal rotary bodies etc, PS30-50 Fixed Fire Fighting Water Monitor can be used for horizontal rotation, pitching rotation, and can achieve reliable positioning locked, which helps the firefighters evacuated from the fire and protect the personal safety of firefighters.
b. PS30-50 Fixed Fire Fighting Water Monitor has stable performance, flexible operation and easy to maintenance.
c. Low inlet pressure
d. Large flow and range far
e. Light weight and small volume.
f. ItPS30-50 Fixed Fire Fighting Water Monitor can spray in close distance, remote monitoring.
g. It can spray water column and water mist use different gun head.
|
Model |
Flow (L/s) |
Water jetting range (m) |
Working pressure (Mpa) |
Max. Angle of elevation (Degree) |
Mini. Angle of Depression (Degree) |
Horizontal Angle (Degree) |
Weight (kg) |
Flange Connection (mm) |
|
|
20 |
≥48 |
0.8~1.0
|
60 |
-40 |
0-360 |
≤35 |
DN80 |
|
|
25 |
≥50 |
||||||
|
PS30 |
30 |
≥55 |
||||||
|
PS40 |
40 |
≥60 |
||||||
|
|
|
|
||||||
|
|
|
|
||||||
|
PS50 |
50 |
≥65 |
||||||
|
|
60 |
≥70 |
0.9~1.2
|
60 |
-40 |
≤45 |
DN100 |
|
|
|
70 |
≥75 |
||||||
|
|
80 |
≥80 |
||||||
|
Note:Flange connection can customized by the user’s special requirement. |
||||||||
