PSS Series Fire Hydrant for Foam System is one of the important apparatus of foam fire extinguishing device, especially suitable for a large area producing, storing and using places where there is a f
Contact Us Product Center
PSS Series Fire Hydrant for Foam System is one of the important apparatus of foam fire extinguishing device, especially suitable for a large area producing, storing and using places where there is a fire hazard with the flammable liquid and combustible liquid.
Foam hydrant is mainly composed of the flange, the transfusion pipe, ball valve, fire pipe, fire pipe teeth and an end cover.
The characteristics of fPSS Series Fire Hydrant for Foam System: Fast switching, portable, is based on the traditional fire hydrant has new creative improve and enhance. Sealed with the lower valve plate, can be with the aid of the medium itself own pressure to seal, the higher the pressure the better the sealing, especially suitable for foam fire fighting line, designed a well lubrication room: The main components selected high corrosion-resistant materials, at the same time, the main parts is inside the oil tank, throughout can get sufficient lubrication, long time no use, no maintenance will not rust, stuck. The foam mixture liquid switch uses stainless steel ball valve, to ensure opening with easy.
PSS Series Fire Hydrant for Foam System suitable for equipment to oil and chemical enterprises, oil refineries, oil storage tanks area, airports etc. important places. It is a kind of special fire equipment which is installed on the foam mixing liquid pipeline to supply the foam mixture liquid to the foam jet equipment.
|
|
Nominal Diameter |
Connector StandardXQTY |
Rated Working |
|
PSS 80-50*2 |
80 |
50*2 |
1.6 |
|
PSS 100-65*2 |
100 |
65*2 |
|
|
PSS 150-65*2 |
150 |
65*2 |
