Advanced detection and discrimination algorithms
Contact Us Product Center
1 2 or 4 wire models
2 Advanced detection and discrimination algorithms
3 Easy installation and maintenance
4 Sleek low-profi le housing design
5 Durable sensor head, no need for replacement
6 SMD circuit board design-satisfactory quality and reliability guaranteed
7 N/C (normal/close)-N/O (normal/open)selectable relay output
8 AR (Auto Reset) function for security systems (optional for 4 wire models) Sensor 9 base option: standard and Shottky Diode
10 Five-year limited warranty
| Response Temperature: | Fixed termperature: 57°C (135°F) or Rate-of-Rise |
| Ceiling Spacing: | 40-50 foot rating for heat sensor |
| Reset Voltage: | less than 1 volt |
| Alarm Indicator: | LED continuously emitting red light |
| Remote Output: | 25 mA max., diode gate |
| Temperature Range: | -10°C to 50°C |
| Permissible Current: | 80mA maximum |
| Humidity: | 0 to 95% RH, no condensation or icing |
| Alarm Contact: | Form A: 1.0A@30VDC/0.5A@125VAC |
| Dimensions: | 100mm (dia) x 46mm (ht) with base |
| Weight: | 120g/set with base |
