This fire pump has features of compact structure, start convenient, fast water, low fuel consumption, light weight and reliable, so that is more suitable for using in the narrow roads. It is the idea
Contact Us Product CenterThis fire pump has features of compact structure, start convenient, fast water, low fuel consumption, light weight and reliable, so that is more suitable for using in the narrow roads. It is the ideal equipment for fire extinguishing used in fire brigade, professional fire brigade, forest fire brigade, towns, rural areas, the mining industry and obligation fire brigade.
| Model | JM100P |
| Port diameter mm (inch") | 100mm (4") |
| Rated capactity(m3/h) | 80 |
| Max discharge capactity(m3/h) | 90 |
| rated Head lift (m) | 18 |
| Max. Head lift (m) | 19 |
| Max.suction head(m) | 7 |
| Engine type | Single cylinder, 4-stroke, air- cooled ,Vertical,Gasolineengine |
| Max.engine output HP) | 10 |
| displacement (CC) | 418 |
| Fuel tank capacity (L) | 12.5 |
| Starting system | recoil |
| Fuel consumption (g/kw.h) | 288 |
| continuous work hours | 8 |
| Machine weight (kg) | 80 |
| MOQ | 1 |
